Thermometer
Bimetal Thermometer DIN 16160 – Part 2
This thermometer is designed for indication of oil temperature in both transformers with expansion conservator or hermetically sealed type transformers. It is fitted with two electric switches and a maximum indicating pointer. The thermometer operates efficiently under very hot and very cold weather conditions.
Do you have questions about our product, would you like personal advice, or do you want to place an order? Our team is happy to assist you with help and guidance!
Construction
All components are surface treated or made of corrosion resistant materials. The temperature sensing element is a bimetal helix. Setting of the contacts is indicated on the indicating scale.
Case
The casted aluminium alloy with electrostatic powder paint. Clear transparent plastic window of UVresistant polycarbonate. Weatherproof according to DIN 40050 protection class IP 43IP 55.
Switches
Two micro switches rated at 5 A 250 VAC or 0.2A 250 VDC. Electrically separated switching circuits. The switches close on temperature rise. Insulation tested to ground at 2000 V for 1 minute.
Maximum indicating pointer
Resettable from the outside by means of a knob.
Measuring range
10-120 °C
Measuring and switching accuracy
±5°C between 50 and 120°C
